Test 4: Canon 350D with my Canon 50 mm, f/1.8 Lens
(at Trader Jim's -- Culver City)


The photo was taken with a Canon 50 mm f/1.8 lens.  Aperture Priority at f/2.8, 1/250 second, iso 800, available light.
Fine JPG, 2304 X 3456 pixels (large).  Parameter 1: moderate increase in sharpness, contrast and color saturation.
Confirmed auto-focus centered over the eye.


f/2.8 image from Canon 50 mm f/1.8 lens on a Canon 350D
.

First photo
Jim's Culver City Camera
Canon 50 mm, f/1.8 lens on a Canon Digital Rebel XT (350D)
Shot at: f/2.8, 1/250 sec, iso 800, large-fine JPG, Parameter 1.
Full frame.  Asymmetric available light.  Auto-focus on eye.
 No Photoshop enhancement.





Second photo from the top:
Jim's Culver City Camera
Jim's Canon 350D with my Canon 50 mm f/1.8 shot at f/2.8, full frame, with unsharp mask applied
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0




third photo:
Jim's Culver City Camera
Same f/2.8 photo as above but cropped with mild sharpening in Adobe Photoshop with unsharp mask
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0



***********************************************





All photos below taken with same Canon 50 mm f/1.8 lens, Parameter 1 and shot with autofocus at f/2.8 on a tripod with new Canon 350D
(10-20-2005)




New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, hand held with unsharp mask applied
(like second photo, except shorter camera to object distance and not centered on eye)
Cyan dot marks the center auto-focus point
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





New Canon 350D, 50 mm f/1.8 at f/2.8, cropped image, hand held with unsharp mask applied
(like third photo except shorter camera to object distance and not centered on eye)
Cyan dot marks the center auto-focus point
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





Flower photo by James Foster with my Canon 50 mm f/1.8 lens at f/2.8 on my Canon 350D (Buydig)
Exposure: 1/200 sec, Focal Ratio: f/2.8, Auto-focus: center on the stamens, Flash, ISO:200, Raw File
.
Image Processing
Smart Sharpen: Amount 300%, Pixel: 0.8
Selective Levels to the center with slight darkening of entire image





200% crop of image above





New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, NO image sharpening (like first photo)
The Autofocus used was the single center focus point method.  Camera to object distance is 38-inches






New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, with unsharp mask applied (like second photo from the top)
The Autofocus used was the single center focus point method.  Camera to object distance is 38-inches
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, NO image sharpening (like first photo)





New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, with unsharp mask applied (like second photo from the top)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





New Canon 350D, 50 mm f/1.8 at f/2.8, cropped, with unsharp mask applied
(like third photo of eyes, except greater crop on the
license plate)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





New Canon 350D, 50 mm f/1.8 at f/2.8, 100% crop, with unsharp mask applied
(like third photo of eyes, except greater crop (100%) on the
license plate)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, NO image sharpening (like first photo)






New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, with unsharp mask applied (like second photo from the top)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0






New Canon 350D, 50 mm f/1.8 at f/2.8, cropped, NO image sharpening





New Canon 350D, 50 mm f/1.8 at f/2.8, cropped, with unsharp mask applied
(like third photo of eyes, except greater crop on stone wall than eyes)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





New Canon 350D, 50 mm f/1.8 at f/2.8, full frame, with unsharp mask applied (like second photo from the top)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0



***********************************************
**********************************************************



All photos below taken with my Canon 35-135 mm f/4.5-5.6 zoom lens, Parameter 1 and shot with autofocus and closed one aperture stop on a tripod with new Canon 350D (10-20-2005)




New Canon 350D, 35-135 mm f/4.5-5.6 zoom lens at 35 mm, f/5.6 (closed 1-stop), full frame, with unsharp mask applied (like second photo from the top)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0





New Canon 350D, 35-135 mm f/4.5-5.6 zoom lens at 135 mm, f/8 (closed 1-stop), full frame, with unsharp mask applied(like second photo from the top)
Unsharp Mask Settings
Amount 200%
Radius 0.4
Threshold 0
