M17 "Omega or Swan Nebula"
M17 is an emission nebula just south of M16. file: M17-240sX28p2-6202023a.jpg Photographic Data telescope: Celestron 9.25-inch EdgeHD SCT at f/7 (focal length= 1,637 mm mm)
mount:
ZWO AM5 harmonic/strainwave Mount Guide Settings in Asiair Plus: Calibrate Step: 5,000 ms Dec Duration: 3,000 ms RA Duration: 2,000 ms Aggression: 50% for both RA & Dec Exposure time for guiding: 1 second
Guiding hardware:
SVBony 60 mm f/4 guidescope (fl=240 mm) Guide Camera: ZWO ASI662MC color planetary camera (2.97 micron pixels) controller/computer ZWO Asiair Plus via WiFi to Samsung S7+ tablet . imaging camera: ZWO ASI533MC-Pro one-shot color astro-camera cooled to 14-degrees F with Optolong L-eNhanced nebular filter . exposures: 240 seconds X 28 (112-minutes)
processing
Stacked in Asiair Plus and cropped and post-processed in Adobe Photoshop Elements . photographic site: West Los Angeles http://mstecker.com/pages/chhouses_fp.htm (Bortle 9 light polluted sky) |
