M27 "Dumbbell Nebula",
short exposure on 6-21-2023
M27 is a planetary nebula in the constellation Vulpecula. file: M27full 30sto120sP1-6212023b1.jpg Photographic Data telescope: Celestron 9.25-inch EdgeHD SCT at f/7 (focal length= 1,637 mm)
mount:
ZWO AM5 harmonic/strainwave Mount Guide Settings in Asiair Plus: Calibrate Step: 5,000 ms Dec Duration: 3,000 ms RA Duration: 2,000 ms Aggression: 50% for both RA & Dec Exposure time for guiding: 1 second
Guiding hardware:
SVBony 60 mm f/4 guidescope (fl=240 mm) Guide Camera: ZWO ASI662MC color planetary camera (2.97 micron pixels) controller/computer ZWO Asiair Plus via WiFi to Samsung S7+ tablet . imaging camera: ZWO ASI533MC-Pro one-shot color astro-camera cooled to 14-degrees F with Optolong L-eNhanced nebular filter . exposures: 120 seconds X 30 (60-minutes)
processing
Stacked in Asiair Plus and cropped and post-processed in Adobe Photoshop Elements . photographic site: West Los Angeles http://mstecker.com/pages/chhouses_fp.htm (Bortle 9 light polluted sky) |
M27 "Dumbbell Nebula"
longer exposure on 8-15-2023
mount:
Guiding hardware:
processing |
M27 "Dumbbell Nebula" with Optolong L-Pro filter on 9-23-2023 file: M27-120sX51P2L-ProCel925f7ASI533-9232023b2.jpg
Photographic Data |
M27 "Dumbbell Nebula" wide-field with Optolong L-Pro filter on 9-25-2023 file: M27-180sX14P2Cel925f7ASI2600DuoL-Pro-9252023b1a.jpg
Photographic Data |
